節能單片機專用音叉晶體ABS07-120-32.768KHZ-T
Abracon的ABS07系列3.2x1.5x0.9毫米音叉石英晶體一直是廣泛應用于從工業和醫療電子產品到消費物聯網設備的工廠解決方案。隨著下一代MCU的廣泛使用，對低電鍍負載(低至4.0pF)版本的ABS07的需求越來越大。與此同時，業界不斷將最終產品設計小型化的趨勢已經讓位于對2.0x1.2x0.6mm音叉石英晶體的需求，這種需求以Abracon的ABS06系列產品為代表。特別是Abracon的ABS06-107在4.0pF電鍍負載下引起了廣泛的興趣。它是低電鍍負載與優化等效串聯電阻(ESR)性能的獨特組合，非常適合節能型gorilla芯片。
然而，1.6x1.0x0.5mm ABS05系列可以輕松取代當前設計中更大尺寸的ABS06和ABS07系列貼片晶振，而不會犧牲性能要求或增加額外的設計壓力。它還可以進一步減少新設計中消耗的表面積。節能單片機專用音叉晶體ABS07-120-32.768KHZ-T
節能單片機專用音叉晶體ABS07-120-32.768KHZ-T，ABS05器件采用最先進的調諧技術，有效振蕩器環路負載電容為4.0pF，設置容差為20ppm和25ppm。此外，ESR經過優化，最大閾值保持在90kω，與最新的節能MCU和其它gorilla芯片組配合使用時，能夠穩定工作。此外，由于最近的供應鏈問題，設計師可能希望在他們的設計中考慮一個全面的、無所不包的土地模式。這種方法支持在同一布局內使用無源晶振ABS07、ABS06或ABS05封裝來滿足設計要求，從而提供了設計靈活性。應用于：物聯網 產業的 衛生保健 智能卡 超薄設備 可穿戴設備，便攜式設備
原廠編碼
品牌
型號
系列
頻率
ABS25-32.768KHZ-T
Abracon晶振
ABS25
kHz Crystal (Tuning Fork)
32.768kHz
ABS25-32.768KHZ-6-T
Abracon晶振
ABS25
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS25-32.768KHZ-1-T
Abracon晶振
ABS25
kHz Crystal (Tuning Fork)
32.768kHz
ABS25-32.768KHZ-6-1-T
Abracon晶振
ABS25
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-120-32.768KHZ-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-9-D-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-D-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-7-D-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-7-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-9-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS13-32.768KHZ-T
Abracon晶振
ABS13
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-7-1-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-9-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-7-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS06-107-32.768KHZ-T
Abracon晶振
ABS06
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-6-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-9-1-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-7-1-T
Abracon晶振
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS06-32.768KHZ-T
Abracon晶振
ABS06
kHz Crystal (Tuning Fork)
32.768kHz
ABS07AIG-32.768KHZ-6-1-T
石英晶體
ABS07AIG
kHz Crystal (Tuning Fork)
32.768kHz
ABS06-32.768KHZ-1-T
Abracon晶振
ABS06
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-9-1-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS06-32.768KHZ-9-1-T
Abracon晶振
ABS06
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-6-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
ABS10-32.768KHZ-T
Abracon晶振
ABS10
kHz Crystal (Tuning Fork)
32.768kHz
ABS10-32.768KHZ-7-T
Abracon晶振
ABS10
kHz Crystal (Tuning Fork)
32.768kHz
ABS10-32.768KHZ-9-T
Abracon晶振
ABS10
kHz Crystal (Tuning Fork)
32.768kHz
ABS07-32.768KHZ-1-T
Abracon晶振
ABS07
kHz Crystal (Tuning Fork)
32.768kHz
| ABS09-32.768KHZ-9-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 音叉表晶 |
| ABS09-32.768KHZ-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS10-32.768KHZ-1-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS09-32.768KHZ-7-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07-LR-32.768KHZ-6-1-T | Abracon晶振 | ABS07-LR | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07L-32.768KHZ-T | Abracon晶振 | ABS07L | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS09-32.768KHZ-1-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS25-32.768KHZ-4-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS25-32.000KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32kHz |
| ABS25-38.000KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 38kHz |
| ABS07AIG-32.768KHZ-6-D-T | Abracon晶振 | ABS07AIG | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS06-32.768KHZ-9-T | Abracon晶振 | ABS06 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS06L-32.768KHZ-T | Abracon晶振 | ABS06L | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07-LR-32.768KHZ-6-T | Abracon晶振 | ABS07-LR | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07-32.768KHZ-4-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS25-60.000KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 60kHz |
| ABS25-100.000KHZ-T | 進口32.768K音叉晶體 | ABS25 | kHz Crystal (Tuning Fork) | 100kHz |
| ABS07AIG-32.768KHZ-T | Abracon晶振 | ABS07AIG | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07AIG-32.768KHZ-1-T | Abracon晶振 | ABS07AIG | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS05-32.768KHZ-T | Abracon晶振 | ABS05 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS05-32.768KHZ-9-T | Abracon晶振 | ABS05 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS10-32.768KHZ-4-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS09-32.768KHZ-4-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS06-32.768KHZ-6-T | Abracon晶振 | ABS06 | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07W-32.768KHZ-D-1-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07W-32.768KHZ-D-2-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07W-32.768KHZ-J-2-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07W-32.768KHZ-J-1-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07W-32.768KHZ-K-2-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz |
| ABS07W-32.768KHZ-K-1-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz |
節能單片機專用音叉晶體ABS07-120-32.768KHZ-T，Abracon總部位于德克薩斯州奧斯汀市外，通過提供創新的高性能頻率控制和時序、電感和連接以及RF和天線解決方案，幫助全球客戶設計下一代產品。Abracon專注于技術專長、卓越服務，并通過全球分銷網絡提供可靠的電子元件，從而加快客戶的上市時間。Abracon以服務、質量和技術知識為公司的核心，在數據通信、運輸、工業、醫療、航空航天、國防等市場中推動創新的互聯技術。
