能代替微型時鐘晶振的GEYER微型振蕩器

來源：億金電子查看手機網址

掃一掃!

掃一掃!

瀏覽：- 發布日期：2024-03-02 08:55:25【大中小】

分享到：

Alternative zum Uhrenquarz in Miniaturformat
Mit der Modellbezeichnung KXO-V93T bietet GEYER Crystal nun schon seit paar Jahrenerfolgreich Oszillatoren in einer bereits etablierten Miniaturisierung an.
Durch die kleinen Abmessungen von nur 1.6 x 1.2 mm und einer Bauh?he von 0.6 mm,ist dieser SMD-Oszillator im Frequenzbereich 1 – 80 MHz, bei geringem Stromverbrauch,besonders schock- und vibrationsfest.
Der Markt sucht zunehmend nach einer lternative zu einem Uhrenquarz (32,768kHz), die nicht nur die Bauform, sondern vor allem die technischen Parameter der herk?mmlichen Uhrenquarze überbieten soll.
Unsere Antwort darauf ist ein 32,768kHz Oszillator in der etablierten KXO-V93T Bauform, mit einer niedrigen Frequenztoleranz über den erweiterten -40° +85°C Temperaturbereich,niedrigen Jitterwerten, Tri-State Funktion und einer geringen Stromaufnahme.
Dieser Oszillator l?st die Stabilit?tsprobleme über den Temperatur- und Spannungsbereich der herk?mmlichen Uhrenquarze und wird nebst den g?ngigen Applikationen für Schwingquarze in allen Branchen eingesetzt, die diese Frequenz ben?tigen, z.B. Industrie Automation, Medical Equipment, IoT, M2M, Wireless Sensors, Sicherheitstechnik.

Der GEYER Electronic KXO-V93T 32,768kHz Oszillator ist ein zukunftsorientiertes Bauteil, das den stringentesten technischen Marktanforderungen gerecht wird: Frequenztoleranz,Anschwingzeit, Stromaufnahme.

geyer1

微型時鐘晶振的替代品
近年來，GEYER晶振已成功推出了 KXO-V93T 型微型振蕩器。
這款頻率范圍為 1 - 80 MHz 的 SMD 振蕩器尺寸小，僅為 1.6 x 1.2 mm，高度僅為 0.6 mm，特別耐沖擊和振動，功耗低。
市場正在越來越多地尋找一種替代時鐘晶體（32.768 kHz）的產品，這種產品不僅在設計上更勝一籌，最重要的是在技術參數上也優于傳統的時鐘晶體。
我們的答案是采用 KXO-V93T 成熟設計的 32.768kHz 振蕩器，在擴展的 -40° +85°C 溫度范圍內具有低頻率容差、低抖動值、三態功能和低功耗。
該振蕩器解決了傳統時鐘晶體在溫度和電壓范圍內的穩定性問題，除了振蕩晶體的常規應用外，還可用于所有需要該頻率的行業，如工業自動化、醫療設備、物聯網、M2M、無線傳感器、安全技術等。
GEYER Electronic KXO-V93T 32.768kHz 石英晶體振蕩器是一款面向未來的元件，可滿足最嚴格的市場技術要求：頻率公差、沉淀時間、電流消耗。

編碼	描述	型號	尺寸	頻率	負載	頻率容差
12.87000	32.7680 kHz Quartz SMD KX-327VT	KX-327V	1.25 \| 1.05 \| 0.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87001	32.7680 kHz Quartz SMD KX-327VT	KX-327V	1.25 \| 1.05 \| 0.5 mm	32.768 kHz	9 pF	± 20 ppm
12.87002	32.7680 kHz Quartz SMD KX-327VT	KX-327V	1.25 \| 1.05 \| 0.5 mm	32.768 kHz	7 pF	± 20 ppm
12.87034	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	4 pF	± 20 ppm
12.87080	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87081	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	6 pF	± 20 ppm
12.87083	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	6 pF	± 20 ppm
12.87086	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	6 pF	± 10 ppm
12.87090	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 10 ppm
12.87095	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 10 ppm
12.87105	32,7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	6 pF	± 10 ppm
12.87107	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87109	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12 pF	± 15 ppm
12.87110	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87111	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87112	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87113	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87114	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87115	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87116	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87118	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	6 pF	± 20 ppm
12.87119	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	6 pF	± 20 ppm
12.87120	32.7680 kHz Quartz SMD KX-327XS	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87121	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87123	32.7680 kHz Quartz SMD KX-327XS	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	6 pF	± 30 ppm
12.87126	32.7680 kHz Quartz SMD KX-327XS	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87127	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	6 pF	± 30 ppm
12.87128	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	6 pF	± 20 ppm
12.87129	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87130	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87131	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87132	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 20 ppm
12.87133	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87134	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 10 ppm
12.87135	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 20 ppm
12.87136	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87137	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	9 pF	± 20 ppm
12.87138	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87139	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 10 ppm
12.87143	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 20 ppm
12.87144	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 5.0 ppm
12.87145	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87146	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 10 ppm
12.87147	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 10 ppm
12.87148	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 20 ppm
12.87149	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 20 ppm
12.87150	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87151	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 30 ppm
12.87152	32.7680 kHz Quartz SMD KX-327NHH	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87153	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 20 ppm
12.87155	32.7680 kHz Quartz SMD KX-327NHE	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87157	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87158	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87159	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87160	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87161	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87163	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	7 pF	± 20 ppm
12.87164	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 30 ppm
12.87165	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 20 ppm
12.87166	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87167	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87168	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 20 ppm
12.87169	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 10 ppm
12.87170	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87171	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87172	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	9 pF	± 20 ppm
12.87173	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	9 pF	± 10 ppm
12.87174	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	7 pF	± 20 ppm
12.87175	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	7 pF	± 10 ppm
12.87176	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	7 pF	± 20 ppm
12.87177	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87178	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	4 pF	± 20 ppm
12.87180	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 20 ppm
12.87181	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87182	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 20 ppm
12.87183	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87186	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87187	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	6 pF	± 20 ppm
12.87188	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 20 ppm
12.60000	16.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	12 pF	± 20 ppm
12.60001	27.120 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	27.120 MHz	10 pF	± 30 ppm
12.60003	26.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	26.0 MHz	12 pF	± 30 ppm
12.60004	13.8240 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	13.8240 MHz	12 pF	± 30 ppm
12.60005	26.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	26.0 MHz	10 pF	± 10 ppm
12.60006	16.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	10 pF	± 20 ppm
12.60007	14.74560 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	14.74560 MHz	16 pF	± 30 ppm
12.60009	25.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	25.0 MHz	20 pF	± 20 ppm
12.60010	16.3840 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	16.3840 MHz	18 pF	± 20 ppm
12.60011	40.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	40.0 MHz	8 pF	± 10 ppm
12.60012	16.0 MHz Quartz SMD KX-7E	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	16 pF	± 30 ppm
12.60013	50.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	50.0 MHz	18 pF	± 30 ppm
12.60014	13.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	13.0 MHz	10 pF	± 30 ppm
12.60015	12.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	12.0 MHz	16 pF	± 30 ppm
12.60016	12.0 MHz Quartz SMD KX-7F	KX-7	3.2 \| 2.5 \| 0.8 mm	12.0 MHz	12 pF	± 30 ppm
12.60017	32.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	32.0 MHz	8 pF	± 10 ppm
12.60018	24.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	24.0 MHz	18 pF	± 13 ppm
12.60019	26.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	26.0 MHz	18 pF	± 30 ppm
12.60020	12.0 MHz Quartz SMD KX-7F	KX-7	3.2 \| 2.5 \| 0.8 mm	12.0 MHz	8 pF	± 10 ppm
12.60021	16.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	7 pF	± 10 ppm
12.60022	8.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	8.0 MHz	8 pF	± 20 ppm
