當前位置：首頁 » 歐美晶振 » M3028S00970.656000,M3028差分晶振,VCXO有源壓控晶振

B

1

M3028S00970.656000,M3028差分晶振,VCXO有源壓控晶振

M3028S00970.656000晶振的核心競爭力在于差分輸出抗干擾能力與VCXO壓控可調特性的協同作用:相較于單端輸出晶振,其差分輸出接口(以LVPECL差分晶體振蕩器為例,輸出擺幅350mV~850mV,共模電壓1.3V~2.0V)可通過差分信號傳輸原理抵消傳輸路徑上的共模噪聲(如電源噪聲,電磁輻射干擾),時鐘信號信噪比(SNR)提升30%以上,即使在長距離傳輸(如PCB板上傳輸距離≥20cm)或多模塊密集布局場景中,仍能保持信號完整性,避免時序錯亂.而VCXO壓控功能則賦予時鐘信號"動態校準”能力:當設備因環境溫度變化(如戶外通信基站晝夜溫差),電源電壓波動導致頻率偏移時,外部控制系統可通過實時調整控制電壓,將頻率偏差修正至±1ppm以內,確保設備時鐘與系統基準時鐘(如GPS同步時鐘)保持嚴格同步,這一特性對需要長期穩定運行的通信設備(如5G核心網傳輸設備),精密測量儀器(如矢量網絡分析儀)至關重要.此外,產品還具備低相位噪聲特性(典型值-120dBc/Hz@1kHz偏移,-145dBc/Hz@100kHz偏移),可減少時鐘信號對射頻模塊的干擾,提升設備整體性能.

2

M3028S00970.656000,M3028差分晶振,VCXO有源壓控晶振

原廠型號 Originalmodel： M2532S135 7.372800 品牌brand： MTRONPTI麥特倫皮
Manufacturer品牌 MTRONPTI麥特倫皮 OperatingTemperature溫度 -40℃ to +85℃
Series型號 M2532高密度晶振 Current-Supply(Max)  -
Type類型 XO (Standard) PackageHeight高度 1.2MM
Frequency頻率 7.3728M Termination  腳位 4 pad
輸出方式 Output： HCMOS PackageType  封裝類型 4-SMD
Voltage-Supply電壓 3.3V Packaging  包裝 TapeandReel
FrequencyStability頻率穩定度 ±50 ppm 安裝方式 Installation： Surfacemount
Size/Dimension尺寸 2.5 X 3.2 mm 最小包裝數MPQ： 3000

3

M3028S00970.656000,M3028差分晶振,VCXO有源壓控晶振

M3028 5070 VCXO LVPECL LVDS

C

M3028S00970.656000,M3028差分晶振,VCXO有源壓控晶振

M220168MPJ 156.250000 M220x XO ±20 ppm 156.25 ±20 ppm ±3 ppm 9.0 X 14.0 mm -20°C to +70°C
MH13FAD-R 16.000000 M3H and MH XO ±100 ppm 16 ±100 ppm ±2 ppm 8-Pin DIP 0?C to +70?C
1698-065 18.600000 MHO+ XO ±25 ppm 18.6 ±10 ppm ±2 ppm 14 Pin DIP -40?C to +85?C
1674-005 44.736000 MV3 and MV5 VCXO ±50 ppm 44.736 ±50 ppm ±0.5 ppm 5.0 x 7.0 mm -40°C to +85°C
1674-007 19.440000 MV3 and MV5 VCXO ±50 ppm 19.44 ±50 ppm ±0.5 ppm 5.0 x 7.0 mm -40°C to +85°C
1674-008 32.768000 MV3 and MV5 VCXO ±50 ppm 32.768 ±50 ppm ±0.5 ppm 5.0 x 7.0 mm -40°C to +85°C
1674-009 25.000000 MV3 and MV5 VCXO ±50 ppm 25 ±50 ppm ±0.5 ppm 5.0 x 7.0 mm -40°C to +85°C
1674-013 38.880000 MV3 and MV5 VCXO ±50 ppm 38.88 ±50 ppm ±0.5 ppm 5.0 x 7.0 mm -40°C to +85°C
XO9085-002 XO9085 OCXO ±100 ppb 100 ±100 ppb ±0.5 ppm Rackmount 0?C to +50?C
XO9085-004 XO9085 OCXO ±100 ppb 100 ±100 ppb ±0.5 ppm Rackmount -40?C to +75?C
M60532JCN 25.000000 M6053 and M6054 TCXO ±1 ppm 25 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40?C to +85?C
M60532JSN 10.000000 M6053 and M6054 TCXO ±1 ppm 10 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40?C to +85?C
M6053S023 32.000000 M6053 and M6054 TCXO ±2.5 ppm 32 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40?C to +85?C
M6053S036 50.000000 M6053 and M6054 TCXO ±2 ppm 50 ±1.5 ppm ±1 ppm 3.2 X 5.0 mm -40?C to +85?C
M60552JSN 48.000000 M6055 and M6056 TCXO ±1 ppm 48 ±1 ppm ±1 ppm 2.5 X 2.0 mm -40?C to +85?C
M6055S014 10.000000 M6055 and M6056 TCXO ±2 ppm 10 ±2 ppm ±1 ppm 2.5 X 2.0 mm -30?C to +75?C
M6056HGSN 26.000000 M6055 and M6056 VCTCXO ±0.5 ppm 26 ±0.5 ppm ±1 ppm 2.5 X 3.2 mm -30?C to +85?C
M60642GSN 40.000000 M6064 and M6065 TCXO ±0.5 ppm 40 ±0.5 ppm ±1 ppm 2.5 X 2.0 mm -40?C to +85?C
M6064S031 20.000000 M6064 and M6065 TCXO ±1 ppm 20 ±1 ppm ±1 ppm 2.5 X 2.0 mm -40?C to +85?C
60103-339-R 12.000000 M3H and MH XO ±100 ppm 12 ±100 ppm ±2 ppm 8-Pin Gull-Wing -55?C to +105?C
60110-239-R 1.000000 M3H and MH XO ±100 ppm 1 ±100 ppm ±2 ppm 8-Pin Gull-Wing -40?C to +85?C
60153-139-R 24.576000 M3H and MH XO ±100 ppm 24.576 ±100 ppm ±2 ppm 8-Pin Gull-Wing 0?C to +70?C
60184-269-R 18.432000 M3H and MH XO ±25 ppm 18.432 ±25 ppm ±2 ppm 8-Pin Gull-Wing -40?C to +70?C
M61612GTSN 10.000000 M616x VCTCXO ±0.5 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61612JFCN 20.000000 M616x TCXO ±1 ppm 20 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61612JTCN 10.000000 M616x VCTCXO ±1 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61612LTCN 10.000000 M616x VCTCXO ±4.6 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61612MFCN 10.000000 M616x TCXO ±0.2 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61613LFSN 50.000000 M616x TCXO ±4.6 ppm 50 ±1 ppm NS 5.0 x 7.0 mm -55°C to +105°C
M61616LTCN 10.000000 M616x VCTCXO ±4.6 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -20°C to +70°C
M61641GFCN 10.000000 M616x TCXO ±0.5 ppm 10 ±1 ppm NS 5.0 x 7.0 mm 0°C to +70°C
M61641GFCN 40.000000 M616x TCXO ±0.5 ppm 40 ±1 ppm NS 5.0 x 7.0 mm 0°C to +70°C
M61642GFCN 24.000000 M616x TCXO ±0.5 ppm 24 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642GFSN 20.000000 M616x TCXO ±0.5 ppm 20 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642GTSN 40.000000 M616x VCTCXO ±0.5 ppm 40 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642JFCN 20.000000 M616x TCXO ±1 ppm 20 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642JFCN 50.000000 M616x TCXO ±1 ppm 50 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642JFSN 10.000000 M616x TCXO ±1 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642JTSN 9.600000 M616x VCTCXO ±1 ppm 9.6 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61642KFSN 10.000000 M616x TCXO ±2 ppm 10 ±1 ppm NS 5.0 x 7.0 mm -40°C to +85°C
M61646PTCN 50.000000 M616x VCTCXO ±0.3 ppm 50 ±1 ppm NS 5.0 x 7.0 mm -20°C to +70°C
M61652GFCN 10.000000 M616x TCXO ±0.5 ppm 10 ±1 ppm ±1 ppm 5.0 x 7.0 mm -40°C to +85°C
M61652GFSN 10.000000 M616x TCXO ±0.5 ppm 10 ±1 ppm ±1 ppm 5.0 x 7.0 mm -40°C to +85°C
M61812GTSN 10.000000 M168x VCTCXO ±0.5 ppm 10 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40°C to +85°C
M61812MFSN 16.384000 M618x TCXO ±0.2 ppm 16.384 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40°C to +85°C
M61812MTSN 16.384000 M618x VCTCXO ±0.2 ppm 16.384 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40°C to +85°C
M61812PFCN 25.000000 M168x TCXO ±0.3 ppm 25 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40°C to +85°C
M61812PTCN 24.576000 M168x VCTCXO ±0.3 ppm 24.576 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40°C to +85°C
M61816GFCN 50.000000 M168x TCXO ±0.5 ppm 50 ±1 ppm ±1 ppm 3.2 X 5.0 mm -20°C to +70°C
M61816PTCN 50.000000 M168x VCTCXO ±0.3 ppm 50 ±1 ppm ±1 ppm 3.2 X 5.0 mm -20°C to +70°C
M6181S020 32.000000 M618x VCTCXO ±0.28 ppm 32 ±1 ppm ±0.5 ppm 5.0 x 7.0 mm -40°C to +85°C
M61822PFSN 8.192000 M168x TCXO ±0.3 ppm 8.192 ±1 ppm ±1 ppm 3.2 X 5.0 mm -40°C to +85°C
HPO-310 66.000000 HPO XO ±5 ppm 66 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-310 77.760000 HPO XO ±5 ppm 77.76 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-311 112.500000 HPO XO ±5 ppm 112.5 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-311 25.000000 HPO XO ±5 ppm 25 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-311 62.208000 HPO XO ±5 ppm 62.208 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-320 66.000000 HPO XO ±5 ppm 66 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-320 77.760000 HPO XO ±5 ppm 77.76 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
HPO-321 112.500000 HPO XO ±5 ppm 112.5 ±5 ppm NS 5.0 x 7.0 mm -55?C to +125?C
