CX532|CX532Z-A2B3C5-70-1966080D18|19.6608|30PPM|18PF|2-SMD，石英晶體諧振器，小的整體包裝，尺寸可在2和4墊，陶瓷表面安裝貼片晶體，Cardinal貼片晶振,四腳貼片晶振,陶瓷晶振,5032晶振,無源晶振,陶瓷晶體諧振器,美國進口晶振,CX532Z-A2B3C5-70-1966080D18晶振,汽車充電槍晶振,汽車電子中控晶振，被廣泛用于通訊設備，無線網絡，藍牙模塊晶振，汽車電子晶振，醫療設備，數碼電子，物聯網應用等。
CX532|CX532Z-A2B3C5-70-1966080D18|19.6608|30PPM|18PF|2-SMD
OperatingTemperature:- 10°C ~ +60°CStandard
FrequencyStability:
±100
±50
±30
ppm
ppm
ppm
Standard
FrequencyTolerance:
±100
ppm
(at25°C)
±50
ppm
Standard
±30
ppm
Load
Capacitance:
Standard 16,
Other values
18 pF or series.
are available.
Resistance:
Maximum resistance corresponds to frequency.
See chart below.
Standard:
Mode: Fundamental or 3rd Overtone
Shunt Capacitance: 7 pF Max
Aging: ± 5 ppm/year
Drive Level: 100 µW Max
CX532|CX532Z-A2B3C5-70-1966080D18|19.6608|30PPM|18PF|2-SMD
| 進口晶振 | 廠家 | 型號 | 系列 | 頻率 | 頻率穩定度 |
| CX532Z-A2B3C5-70-12.288D18 | Cardinal Crystal | CX532 | MHz Crystal | 12.288MHz | ±30ppm |
| CX532Z-A2B3C5-70-16.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 16MHz | ±30ppm |
| CX532Z-A2B3C5-70-12.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 12MHz | ±30ppm |
| CX532Z-A2B3C5-70-1966080D18 | Cardinal Crystal | CX532 | MHz Crystal | 19.6608MHz | ±30ppm |
| CX532Z-A2B3C5-70-33.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 33MHz | ±30ppm |
| CX532Z-A2B3C5-70-27.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 27MHz | ±30ppm |
| CX532Z-A5B3C5-70-20.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 20MHz | ±30ppm |
| CX532Z-A2B3C5-70-14.7456D18 | Cardinal Crystal | CX532 | MHz Crystal | 14.7456MHz | ±30ppm |
| CX532Z-A5B3C5-70-12.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 12MHz | ±30ppm |
| CX532Z-A2B3C5-70-50.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 50MHz | ±30ppm |
| CX532Z-A2B3C5-70-30.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 30MHz | ±30ppm |
| CX532Z-A5B3C5-70-27.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 27MHz | ±30ppm |
| CX532AZ-A5B2C5-70-25.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 25MHz | ±50ppm |
| CX532Z-A5B3C5-70-25.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 25MHz | ±30ppm |
| CX532Z-A2B3C5-70-20.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 20MHz | ±30ppm |
| CX532Z-A2B3C5-70-8.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 8MHz | ±30ppm |
| CX532Z-A5B3C5-70-18.432D18 | Cardinal Crystal | CX532 | MHz Crystal | 18.432MHz | ±30ppm |
| CX532Z-A2B3C5-70-25.0D18 | Cardinal Crystal | CX532 | MHz Crystal | 25MHz | ±30ppm |
